Die Profile
Equal Leg Channel
Symmetrical channel profile used in framing, guides, and structural applications. Tower’s equal leg channels are extruded to precise tolerances and available in consistent dimensions and wall thicknesses.
Available Die Specifications
Standard die configurations.
Each listing represents a verified die currently available for production. Contact sales for pricing, alloy availability, or to discuss a modified version of an existing profile.
Thank you! Your submission has been received!
Oops! Something went wrong while submitting the form.
Location
Die #
A
B
C
T
T1
T2
R
R1
R2
Wt/Ft
Perim
Pipe
Special Notes
Olney
2614
9
1.5
0.188
0.188
0.015
0.015
0.015
2.622
23.624
Olney
15819
10.125
3.25
0.375
0.625
0.375
0.125
0.375
8.852
31.642
Olney
12376
10.5
2
0.25
0.25
0.062
0.015
0.015
4.202
28.447
